GX145 Plate heat exchanger and spare parts (plate and gasket)
We mainly manufacture plate heat exchanger and spare parts (plate
and gasket),we can provide many brands of plates and gasketed plate
heat exchanger with competitive price and high quality,Most
importantly we provide free sample if you are interested.
By keeping most often used plates in stock at all times, we have
the ability to offer immediate shipment on most requests. Our turn
around time and price is unmatched in the industry.
We guarantee every plate sold with equal or longer warranty periods
compared to the original manufacturer. The models we provide can
replace the world famous manufacturers.
GX145 Plate heat exchanger Plates Gaskets Specification in Heat
Exchanger Gaskets
| Material of Plate | Suited liquid Kinds |
| Stainless Steel(SUS304,316 etc) | Pure Water,Normal Water,Mineral Oil etc |
| Ti,Ti-pd | Sea water,Saline water,Mineral water etc |
| 20Cr,18Ni 6Mo(254SMO) | Dilute Sulphuric Acid,Organic water solution etc |
| Ni | High-temp and concentration caustic soda |
| Hastelloy alloy(C276,D205,B2G) | Concentrated sulfuric acid,Hydrochloric acid,Phosphoric acid |
| Thickness of plate | 0.5mm/0.6mm/0.7mm/0.8mm/0.9mm/1.0mm |
| Plate Shape Size | 2072*922mm |
| Plate Center Size | 1720*570mm |
| Corrugation Depth | 4.6mm |
| Angle Hole Diameter | Φ340 |
| Corrugated Angle | 46° /90 °/180 °/0 ° |
| Working Pressure | <= 25 bar |
| Plate Theta | Low Theta and High Theta |
| Plate Hole | Channel Plate with 4 Holes, End Plate without holes |
GX145 Plate heat exchanger advantage
- Small dimension
- High heat transmition
- Flexible assemblyed
- Small metal consumption
- Small heat cost
- Easy to uninstall,wash and maintance
GX145 Plate heat exchanger main components
Tightening bolts---Press the channel plates together
Connections--- Holes through the frame plate, permitting the media
to enter into the heat exchanger.
Support column
Bolt protection
Upper guide bar and Lower guide bar
S-frame and E-frame
Rubber lining
GX145 Gasket Feature
- Simple style and good sealing
- Widely used and adaptable
- Resistant to corrosion and high temperature
- Easy to disassemble and maintain
Application Areas/Occasions
HAVC, Powerplant, Food, Marine, Refinery, Pharmace, Mining,
Chemical, Refrigeration
Why Choose Us?
- We always think from the perspective of customers, solve problems
and bring higher value to customers.
- More than 8 years of professional experience and expert team.
- Professional production RD team to improve heat exchanger
efficiency and reduce operating costs.
- The technical scheme of guaranteed commitment.
- Whole process service from pre-sale to after-sale.
- Help customers reduce risks and save costs to manimize customer
benefit
Package:standard export carton, plywood case
