TL250PP Plate Heat Exchanger Description
Plate heat exchanger is composed of fixed pressure plate, flexible
pressure plate, top and bottom guid bars, back post, support foot,
heat exchanger plate, gasket, roller, tightening bolt,nut,lock
washer and frame foot. It is device for liquid of two different’s
temperture that is going to heat transfer. It is suitable for all
industry, such as chemical engineering,chemical
fertilizer,meicine,metallurgy,machinery,mine,printing and dyeing
and so on.
TL250PP Application
Gasketed plate and frame heat exchangers provide efficient heat
transfer in compact equipment with a small footprint. The units
have a flexible design and easy to service and maintain. The
product range is extremely wide and used in duties for many
industires, Such as:
| Heating | Cooking |
| Cooling | Freezing |
| Pasteurising | Central HVAC |
| Water Heaters | Ancillary Cooling |
| Waste Heat Recovery | Cooling Tower Isolation |
| Heat Pump Installations | Boiler Sepatation Plates |
| Lube Oil Coolers( Turbines) | Thermal ( Ice) Storage Systems |
| Seal Water Coolers ( Vacuum Pumps) | Gearbox Oil Cooling (Wind Turbines) |
| Heating, Ventilating & Air Condition | Industrial Process Liquid Heating and Cooling |
| Concentration in the Food and Dairy Industries | Ground Water Isolation Exchangers( Geothermal) |
| Pharmaceutical-Hygienic Water Heating/Cooling | Brewing-Wort Cooling, Beer/Large/ Cider Condition |
| Chemical Heating and Cooling, Either in-line or on a Batch Process | Food & Dairy- Specialist in milk pasteuring, raw milkcooling, non
viscous food products and CIP wash water heating |
| Marine-(Titanium Plates) for uses such as main engine cooling, oil
cooling, intercoolers and deck wash water heating | |
TL250PP Production Introduction
Basic Information
Plate heat exchanger gasket is one of the important parts of plate
heat exchanger,which can produce plastic deformation and have
certain strength.
M&C’s gaskets are customized to fit the customer’s working
conditions and are manufactured by a professional factory in a
specified size.
The contact width between the high pressure gasket and the sealing
surface is very narrow ( line contact).
Sealing Principle
The corrugated plate is pasted with sealing gasket, which is
designed to double seal structure and has signal hole. When the
medium leaks from the first seal, it can leak out from the signal
hole, and the problem can be detected and solved as soon as
possible, without causing the mixing of the two media. Sealing
gasket according to different media and operation temperature to
choose different types of gaskets.
Material: NBR,EPDM,HNBR,VITON,FKM
Advantage: Produce plastic deformation and have certain strength
